BF-70UA-E-T

All-inclusive model loadable up to 100kg apply to transportation test featuring single axis vertical vibration

· Up/down vibration
· Large sized vibration table: 650x720mm
· Up to 100kg load capacity

Download the Catalogues

Specification

Vibration direction
Up/down
Adjustable displacement range
0.8 - 2.8mmP-P
Vibration table
650 x 722mm
Frequency range
10 - 67Hz (0.1Hz unit)
Acceptable acceleration range
98m/s² (10G)
Maximum loading weight
100kg
Operation mode
MANUAL / RANDOM / SWEEP
Temperature
0 - 40℃ (No condensation)
Power source
AC200 - 240V 3phase 50/60Hz 4A or below
Dimensions & weight
650(W) x 722(D) x 650(H)mm / approx. 125kg
